Gasoline Diesel Motorized Powered Winch 5 Ton Double Drum Hand Tractor Winch
A Gasoline/Diesel Motorized 5 Ton Double Drum Hand Tractor Winch is a powerful, engine-driven winch designed primarily for heavy-duty cable pulling, tensioning, and stringing tasks in power line construction and related industries.
- Transmission Line Wire Cable Conductor Tension Stringing Equipment
- Transmission Conductor Tension Stringing Equipment For Overhead Power Lines
- Tools For Power Lines,Substation,Electrical Construction & Maintenance
- Electric Power Transmission Distribution Line Construction Machine Tools
- Overhead Power Transmission Distribution Line Repair Hardware Fittings
- Underground Cable Laying Pulling Installation Equipment Machine Tools Accessories
- Information
- Video
A Gasoline/Diesel Motorized 5 Ton Double Drum Hand Tractor Winch is a powerful, engine-driven winch designed primarily for heavy-duty cable pulling, tensioning, and stringing tasks in power line construction and related industries.
-
: Typically rated for a 5-ton (approximately 50 kN) pulling force, suitable for pulling heavy cables, erecting poles, and stringing conductors.
-
: Equipped with two drums allowing simultaneous or alternate cable handling, improving efficiency in cable laying and tensioning operations.
-
: Powered by a gasoline or diesel engine, often with around 15 HP and 2000 RPM, providing strong and reliable traction without dependence on external electric power.
-
: Widely used in overhead power transmission line construction, cable pulling, tower erection, and other heavy mechanical pulling tasks in remote or off-grid locations.
-
:
-
Traction force can reach up to 60 kN (6 tons) depending on gear settings.
-
Traction speeds vary by gear, for example, from about 6 m/min up to 55 m/min for different gear ratios.
-
Ground clearance around 150 mm and wheelbase about 1040 mm for good mobility.
-
Weight ranges from approximately 550 to 600 kg depending on model.
-
-
: Walk-behind or hand tractor style, with simple structure and easy operation. Gearboxes provide multiple speed and traction force options for different pulling needs, including forward and reverse.
-
: Around 2.67 m length, 1.04 m width, and 1.3 m height.
-
:
-
Suitable for rugged terrain due to tractor wheels.
-
Can be customized with different engine brands.
-
Often includes safety features like mechanical brakes and rope tensioners.
-
-
| Parameter | Value |
|---|---|
| Pulling Force | 5 Ton (50 kN), up to 60 kN in some gears |
| Engine Power | ~15 HP gasoline/diesel engine |
| Traction Speed | 6.2 to 55.6 m/min (varies by gear) |
| Weight | 550–600 kg |
| Dimensions (L×W×H) | 2670×1040×1300 mm |
| Ground Clearance | 150 mm |
| Wheelbase | 1040 mm |
| Drum | Double drum |
The 5 Ton Gasoline/Diesel Motorized Double Drum Hand Tractor Winch is a robust, mobile winching solution designed for heavy cable pulling and tensioning in power line construction and other industrial applications. Its double drum design and engine-powered operation provide high efficiency, mobility, and versatility in challenging field conditions
